ISO18000-6C EPC Global Class 1 Gen 2 Ultra High Frequency Tag (UHF1-Tag4)
Short Description:
UHF1-Tag4 is a ultra high frequency encrypted tag for Granding UHF reader.
The UHF Tag is suitable for vehicle management and goods management, and card reading distance will be up to 10 meters for UHF1-10E and UHF1-10F in parking lot applications.
Introduction
UHF1-Tag4 is a ultra high frequency encrypted tag for Granding UHF reader.The UHF Tag is suitable for vehicle management and goods management, and card reading distance will be up to 10 meters for UHF1-10E and UHF1-10F in parking lot applications.
Features
- High Safety
- Long Service Life
- High Reading Rate
- High Chip Sensitivity
- Flexible Storage Structure
- Reading and Writing
- Repeatedly
- Adhesive Design, Easy Installation
- Anti-tear: when torn, it will be destroyed
Typical Applications
- Goods Management
- Vehicle Management
- Highway (Bridge) Toll
- Collection Management
Notes
1.The tag must be mounted on the windshield horizontally in the cab . If there is a metal explosion-proof film above the windshield,you have to cut a small piece off it or roll down the window to read the tag.(the cut area is at least one time the tag ‘s) 2.n order to get the best recognition performance, please keep the tag direction the same as antenna’s polarization direction when using. 3.The working temperature and humidity must be within the allowable range, otherwise it may cause the product to work abnormally. 4.The storage temperature and humidity must be within the allowable range, otherwise it will reduce the service life of the product. 5.The distance from the product 50CM should not have an electric field or a strong current through, which may cause interference to the product. 6.The product can not be placed in a strong acid or alkali environment, which will cause serious damage to the product. 7.The product should be kept away from the magnetic field for storage to prevent data loss.
UHF Tags to Register in the Access3.5 Software
